Description
NEW 20″ WALK-BEHIND SAW – DOWNCUT
Everything you love about the DS-18 with MORE blade capacity and MORE versatility!
Model: DS-20E
BLADE NOT INCLUDED
- 20″ Blade Capacity
- Max Cut Depth: 7.75″
- NEW & Improved throttle cable
- Easy turn crank, for lowering and raising blades in and out of cut
- Heavy-Duty Anti-Vibration engine mount!
- Screw boot belt tensioner prevents frame damage
- 7-gauge steel blade guard with welded protective segment flap
- Heavy-Duty lifting bail for easy loading and unloading
- 7.5HP, 230V Three Phase electric motor
- Heavy-Duty 7-gauge steel laser cut frame
- Large screw-type depth control
- Wide-T handles with rubber grips
- Solid-Steel lifting handles
- High quality molded rubber wheels
- Dual arbor available for 2 saw cuts
- Pro Tip: EDCO recommends to use step cutting when using the saws and not to burry the blade to cut all at once
IDEAL FOR…
- Short-run slab cutting
- Contraction joints
- Patch repairs in asphalt
- Traffic loop installation
- Trenching
EDCOed Training Modules:
Visit EDCOed.com and get training for machines, tooling, how to operate, and maintenance.
